How to Use Phlex Components in Avo

Avo uses ViewComponent to render fields, resources, and other parts of the UI. However, that doesn't mean you can't use Phlex components in your Avo views.

The initialization process between the two is quite similar allowing a smooth transition between them. You just need to configure the component you want to use for a given field or resource on a specific view, and Avo will take care of the rest.

This guide walks you through how to use Phlex components inside your Avo views.

Note: This guide assumes you already have Phlex installed in your app.

Step 1: Create a Phlex component

Let's start with a simple Phlex component for a field. This component uses the same Tailwind CSS classes as the default Avo field component, and includes an additional message about the field.

You can make your components as simple or as complex as you'd like, this is just an example.

WARNING

All Tailwind CSS classes used in this guide are already included in Avo's design system and available in its pre-purged assets. If you plan to customize the appearance beyond what's shown here, consider setting up the TailwindCSS integration.

# app/components/phlex_component.rb
class PhlexComponent < Phlex::HTML
  def initialize(field:, **)
    @field = field
  end

  def view_template
    div class: "flex items-center px-6 py-4" do
      span class: "font-semibold text-gray-500 text-sm w-64 uppercase" do
        @field.name
      end
      span class: "text-gray-900" do
        @field.value
      end
      span class: "text-gray-300 mx-3" do
        "|"
      end
      span class: "mr-1" do
        "ℹ️"
      end
      span class: "text-sm text-gray-500 italic" do
        "This is a unique course link. Share it with enrolled users."
      end
    end
  end
end

---

Step 2: Use the component in your field declaration

With the components option, you can specify the component to be used for the show view of a field.

# app/avo/resources/course_link.rb
class Avo::Resources::CourseLink < Avo::BaseResource
  self.title = :link
  self.model_class = ::Course::Link

  def fields
    field :id, as: :id
    field :link,
      as: :text,
      components: {
        show_component: PhlexComponent
      }
    field :course, as: :belongs_to, searchable: true
  end
end

TIP

While this example uses a field, the same pattern applies to resources. You can use the components option to customize the component for the index, show, edit, and new views.

Conclusion

Even though Avo relies on ViewComponent under the hood, you're free to use Phlex components in your Avo views.

This guide covered a basic example, but Phlex is capable of much more. Check out the official Phlex documentation to learn how to build more advanced components.

If you have questions, suggestions, or feedback, join the conversation in the Feedback: Using Phlex Components in Avo Views.
